CLASSIFICATION

 MODE

 ELECTRICAL CHARACTERISTICS

 Operating Voltag

 4.7 ~ 5.3VDC

 Operating

 10~20mA

 Center Frequency

 5.8485GHz (5.847GHz ~5.850GHz)

 Output Power

 < 10mW

 ABSOLUTE MAXIMUM RATING

 DC InputVoltage

 5VDC(4.7 ~ 5.3VDC

 Operating Temperature Range

 - 30 to +50'C

 Storage TemperatureRange

 - 40 to +80'C

 Relative Humidity

 95% at35'C

 GENERAL CONTENTS

 Size

 34mm * 36mm * 8.3mm(PinAnt.:exclusion)

 Detection Range & Angle (Wall) (Ceiling)

 15 ~ 20m(Max.) / 130’ ~150’

 10 ~ 15m Dia(Max.) / 360’

 Radiated MW Energy

 10~30 micro Watt(atleast)
