■ Option
* 속도(1~40km/h)확인기능
* 방향(전/후진)확인기능 (Min 2m, Max 12~15m) 및 전/후진 방향 선택가능
■ Specification
PARAMETER | CONDITIONS | MIN | TYP | MAX | UNITS | |
Radar | ||||||
transmit frequency |
| 24.050 |
| 24.250 | GHz | |
output power (EIRP) |
|
|
| 20 | dBm | |
Sensor | ||||||
max adjustable detection range | motion detection for an R C S = 1m² |
|
| 12~15 | m | |
| switch functionality E.g. Detection of a hand |
|
| 0.1 | m | |
range for direction of movement recognition | E.g. Detection of a person | 2 |
| 12~15 | m | |
activation time switch |
|
| 400 |
| ms | |
velocity range |
| 0.7 |
| 40 | km/h | |
antenna pattern (10dB width) | compare plot on page 3 |
| 43 |
| ° | |
|
|
| 120 |
| ° | |
Power supply | ||||||
supply voltage |
| 12 |
| 15 | V | |
supply current | operation | 80 | 85 | 90 | mA | |
Stand - by | Continuous | 50 |
| 55 | mA | |
| ECO | 10 |
| 15 | mA | ||
Environment | ||||||
operating temperature |
| -20 |
| +60 | °C | |
storage temperature |
| -40 |
| +85 | °C | |
Mechanical Outlines | ||||||
outline dimensions | height length width | 100 (16.0) 123 (34.0) 45 (45.5) | mm | |||
Weight | ||||||
|
| 13.2 | g | |||
